Yuxi Qiaolong cement Co.,Ltd. ---2500TPD

Customer Reviews：

“Huijin cement rotary kiln burner bring significant reduction in coal, power and ammonia consumption! Huijin is an first-class enterprise always do what they say and also offers reasonable price.

Project Introduction：

Since Huijin cement rotary kiln burner was used in Yuxi Qiaolong Cement Co., LTD., the effect of saving coal, power and ammonia water is obvious, which has been highly recognized by customers. According to the actual operation data, the annual cost saving is about 3 million CNY (base on 300 days per year).

contact

Technical parameter comparison table

The main parameters

Original burner

Huijin Burner
Coal consumption at kiln head（t/h）

5.0

4.8
Coal consumption at kiln tail（t/h)

11.6

11.5
Kiln feeding（t/h）

185

188
Secondary air temperature（℃）

1140

1160
Tertiary air temperature（℃）

940

956
C1 outlet temperature（℃）

354

345
Kiln tail temperature（℃）

1150

1142
Primary air amount（m³/min）

80

50
Primary air pressure（kPa）

39

48
Primary air blower current(A)

130

110
Kiln head blower air amount（m³/min)

50

25
Kiln head blower air pressure（kPa）

28

20
Kiln head blower current (A)

70

35
Dosage of ammonia（t/h）

0.6

0.5
Clinker KH value

0.90

0.92
Clinker 3-day strength(MPa)

33

35
Clinker 28-day strength(MPa)

53

55
Standard coal consumption(kg/t)

113

111

Project Introduction

Customer Reviews：

Huijin cement rotary kiln burner has perfect power-saving effect, the ammonia dosage is also significantly reduced.

Customer Reviews：

Huijin cement rotary kiln burner have stable and powerful flame, which indirectly prolong kiln lining service life, and with high flexibility adapt to low value pulverized coal.
