Case-Dafang Yonggui buliding material--3200T/D production line

Customer Reviews：

"Huijin cement rotary kiln burner have significantly improved productivity and we are satisfied with the good effect.”

Project Introduction：

Since Huijin cement rotary kiln burner was used in Dafang Yonggui Building Material Co., Ltd., has reduced the usage of ammonia by 46%, saved electricity by 15%-35%, reduced the standard coal consumption for per ton of clinker by 2kg, and increased the 3-days clinker strength by 1MPa. The clinker output was greatly improved, and the estimated cost-saving is about 2.42 million CNY(calculated based on 300 days a year).

contact

Technical parameter comparison table

The main parameters

Original burner

Huijin Burner
Coal consumption at kiln head（t/h）

9

8.2
Coal consumption at kiln tail（t/h)

12.1

12.6
Kiln feeding（t/h）

221

225
Secondary air temperature（℃）

1100

1120
Tertiary air temperature（℃）

950

970
C1 outlet temperature（℃）

350

345
Kiln tail temperature（℃)

1230

1150
Primary air amount（m³/min）

115

48
Primary air pressure（kPa）

29

58
Primary air blower current(A)

210

112
Kiln head blower air amount（m³/min)

68

28
kiln head blower air pressure（kPa）

28

27
Kiln head blower current (A)

160

43
Clinker KH value

0.9

0.9
Clinker 3-day strength(MPa)

30

31
Clinker 28-day strength(MPa)

56.23

57.03
Ammonia dosage（t/d）

13

7
Clinker standard coal consumption(kg/t))

111

109

Project Introduction

Customer Reviews：

Huijin cement rotary kiln burner has perfect power-saving effect, the ammonia dosage is also significantly reduced.

Customer Reviews：

Huijin cement rotary kiln burner have stable and powerful flame, which indirectly prolong kiln lining service life, and with high flexibility adapt to low value pulverized coal.
