Bijie Saide Cement Co., Ltd.---2500T/D

Customer Reviews：

Huijin cement rotary kiln burner is so impressive with flexible adjustment and adaptability

Project Introduction：

Since the Huijin cement rotary kiln burner was used in Bijie Saide Cement Co., Ltd., the amount of ammonia is reduced by 0.1m³/h, the 3 days strength of clinker was increased by 1MPa, and the clinker standard coal consumption was reduced by 1kg/t.

contact

Technical parameter comparison table

The main parameters

Original burner

Huijin Burner
Coal consumption at kiln head（t/h）

6

5.5
Coal consumption at kiln tail（t/h)

9.5

9.6
Kiln feeding（t/h）

175

180
Secondary air temperature（℃）

1000

1020
Tertiary air temperature（℃）

850

870
C1 outlet temperature（℃）

330

326
Kiln tail temperature（℃)

1200

1180
Primary air amount（m³/min）

42

42
Primary air pressure（kPa）

48

50
Primary air blower current(A)

95

93
Kiln head air blower amount（m³/min)

26

23
Kiln head air blower pressure（kPa）

28

22
Kiln head air blower current(A)

43

39
Dosage of ammonia(t/h）

0.7

0.6
Clinker KH value

0.9

0.9
Clinker 3-day strength(MPa)

28

29
Clincker standard coal consumption(kg/t)

113

112

Project Introduction

Customer Reviews：

Huijin cement rotary kiln burner has perfect power-saving effect, the ammonia dosage is also significantly reduced.

Customer Reviews：

Huijin cement rotary kiln burner have stable and powerful flame, which indirectly prolong kiln lining service life, and with high flexibility adapt to low value pulverized coal.
